T-measurement TDS-100F1
เครื่องวัดอัตราการไหลของเหลวแบบติดผนัง (Wall-Mount Ultrasonic Flow Meter)
- Accuracy: ±1% of reading at rates >0.6 ft/s (0.2m/s). Assume a fully developed flow profile.
- Repeatability: ±0.2%.
- Velocity: ±0.03 ~ ±105 ft/s (±0.01 ~ ±30 m/s), bi-directional
- Display: LCD with backlight. 2x20 letters.
- Keypad: 4x4-key membrane keypad with tactile feedback
- Protection Class: IP65 (NEMA 4X).
- Size: 9.88x7.56x3.15 (251x192x80mm3) for standard version
- Pipe Size: 0.5 ~ 240 (DN15mm ~ DN6,000mm).
- Pipe Material: All metals, most plastics, fiber glass, etc. Allow pipe liner.
- PowerAC: 240V DC: 8VDC~36VDC
- Power consumption: < 2W
- WeightStandard main unit: 3kg
